Description:
ZL1B mechanical seal
For blower pump, diving pump and circulating pump
Replacing the mechanical seal of John Crane 1B

Operational Conditions:
Temperature: -20℃ to +120℃
Pressure: ≤2.5MPa
Speed: ≤15m/s

Seat Type:
Alternative: CT20, T20, T210

Materials:
Stationary Ring: Ceramic (Alumina), Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide, Co-binder Tungsten Carbide
Rotary Ring: Resin Impregnated Carbon Graphite (Furan), Antimony Impreg, Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded, Co-binder Tungsten Carbide, Ni-binder Tungsten Carbide
Secondary Seal: Nitrile (NBR), Ethylene Propylene (EPDM), Fluorocarbon Rubber (Viton)

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluids
