Description:
ZL502 Mechanical Seal
Replacement to:
John Crane type 502 seal
Aesseal B07 seal
Sterling 524 seal
Vulcan 1724 seal

Operational Conditions:
Temperature: -20℃ to +120℃
Pressure: ≤2.5MPa
Speed: ≤15m/s
Seat Type:
Standard:BO
Alternative:BP

Materials:
Stationary Ring: Ceramic (Alumina), Silicon Carbide Reaction Bonded, Silicon Carbide Sintered Pressureless, Ni-binder Tungsten Carbide, Co-binder Tungsten Carbide
Rotary Ring: Resin Impregnated Carbon Graphite (Furan), Antimony Impreg, Carbon Graphite, Silicon Carbide Sintered Pressureless, Silicon Carbide Reaction Bonded, Co-binder Tungsten Carbide, Ni-binder Tungsten Carbide
Secondary Seal: Nitrile (NBR), Ethylene Propylene (EPDM), Fluorocarbon Rubber (Viton)

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluids
