Description:
ZL688  Mechanical Seal
For big compressors and industrial pumps
Replacing the mechanical seal of John Crane 609

Operational Conditions:
Temperature: -75℃ to +400℃
Pressure: ≤2.0MPa
Speed: ≤23m/s

Materials:
Stationary Ring：TC, Silicon Carbide
Rotary Ring：Carbon ,Silicon Carbide,TC
Secondary Seal：NBR,EPDM,Viton
Bellows：Steel
Spring and Metal Parts：Steel

Applications:
Oil, light hydrocarbon,
aromatic Hydrocarbon,
organic solvents,
week acids,
ammonia
