Description:
ZL59U Mechanical Seal
Replacement to:
Burgmann BT-C56.KU seal
John Crane T59U seal
Aesseal M03 seal
Sterling 259 seal

Operational Conditions:
Temperature: -40℃ to +250℃
Pressure: ≤1.2MPa
Speed: ≤15m/s

Seat Type:
Standard:ZLBP
Alternative:ZLBO

Materials:
Stationary Ring: Silicon Carbide  Reaction Bonded,Ceramic(Alumina),Silicon Carbide   Sintered Pressureless,Ni-binder Tungsten
Rotary  Ring: Antimony Impreg. Carbon Graphite,Resin Impregnated Carbon  Graphite(Furan),Silicon Carbide  Reaction Bonded,Silicon Carbide   Sintered Pressureless,Ni-binder Tungsten  Carbide
Spring and Metal Parts:Stainless Steel,Stainless Steel ,,Hastelloy C-4 Alloy
Secondary Seal:Pure PTFE

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluid
