Description:
ZL9 Mechanical Seal
Replacement to:
John Crane T109, T9, T909 seal
Aesseal M01 seal
Roten 90 seal
Sealol T seal
Sterling 290 seal

Operational Conditions:
Temperature: -40℃ to +250℃
Pressure: ≤1.2MPa
Speed: ≤15m/s

Seat Type:
Standard: 16
Alternative: N, T21

Materials:
Stationary Ring: Silicon Carbide  Reaction Bonded,Ceramic(Alumina),Silicon Carbide   Sintered Pressureless,Ni-binder Tungsten
Rotary
Ring: Antimony Impreg. Carbon Graphite,Resin Impregnated Carbon
Graphite(Furan),Silicon Carbide  Reaction Bonded,Silicon Carbide
Sintered Pressureless,Ni-binder Tungsten
Carbide
Spring and Metal Parts:Stainless Steel,Stainless Steel ,,Hastelloy C-4 Alloy
Secondary Seal:Pure PTFE

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluid
